NCI250 Enduro

ENGINE:

Engine Type

249cc liquid-cooled single-cylinder four stroke

Max Power

21 hp under Euro4 program
26 hp under racing program

Compression Ratio

11.5:1

Fuel Supply

Delphi®  Fuel Injection

Ignition

Electric and Kick

DRIVE TRAIN:

Transmission

6-speed

Final Drive

#520 Chain DID® ; 13T/48T

CHASSIS / SUSPENSION / BRAKES:

Frame

Aluminium alloy

Speedometer

KOSO® digital

Triple Clamp

CNC machined and anodized

Air Filter

Twin Air®

Front Suspension

Fastace® 48mm inverted progressive fork

Rear Suspension

Fastace® single shock with airbag

Front and Rear Brake

Kailing® Off-Road brake system ,                                      Front single 270mm disc, Rear single 240mm disc

Front and Rear Wheel

1.6-21 / 2.15-18, CNC hub with NSK® bearing ,                7075 alloy rim , Stainless steel spokes

Front and Rear Tire

CST® C7202 80/100-21'  |  CST C7203 110/100-18'

Light

R-Tech® Tail light ( from Italy ); LED turn lights; Head light

DIMENSIONS:

Size

2300mm*830mm*1240mm

Wheelbase

1500mm

Seat Height

960mm

Ground Clearance

310mm

Fuel Capacity

8L

Gross Weight

118kg

OTHERS:

Available Colors

White

Optional Genuine Parts：

NISSIN® brakes;  CNC aluminium engine protector;

Aluminium hand protector;  CNC rear rack,

Rear passenger foot pegs;  CNC rear brake caliper cover;

Rear brake pump bracket etc.
